Super Power Digital UPS Model 1700 (24V) DG
SKU: 899-971-1701
CATEGORY: INVERTER/HOME UPS
₹10,000
MRP: ₹10,590
- Weight16.3kg
- Output VoltageSame as INPUT
- Dimensions (L*W*H)43.3x46.3x23.2
SALIENT FEATURES:
- Low Watt Loss EI Core Its Save Electricity.
- Dura Retain Technology for Longer Power Backup.
- Resettable Circuit Breaker for Total Safety of connected appliances.
- Constant Continuous Regulated Charging saves electricity while charging.
- Intelligent Pulse Technology for Faster Charging & More Battery Life.
- Auto Reset Funtion During & After Overload Conditions.
Super Power Digital UPS Model 1700 (24V) DG is a Micro Controller design based, LARGEST SELLING SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Standard Voltage Range from 100V~300V and Narrow Voltage Range from 180V~260V.
Super Power Digital UPS Model 1700 (24V) DG is a Micro Controller design based, LARGEST SELLING SERIES of Extended Backup External Battery UPS Systems. It comes with many user friendly features. It has Voltage Range Selection Switch and can be operated in Standard Voltage Range from 100V~300V and Narrow Voltage Range from 180V~260V.
- Low Watt Loss EI Core Its Save Electricity.
- Dura Retain Technology for Longer Power Backup.
- Resettable Circuit Breaker for Total Safety of connected appliances.
- Constant Continuous Regulated Charging saves electricity while charging.
- Intelligent Pulse Technology for Faster Charging & More Battery Life.
- Auto Reset Funtion During & After Overload Conditions.
- Micro Controller Based Intelligent Control Design.
- LED Display Indications (Status & Fault)
- CCCV Technology with Auto Trickle Mode
- Smart Overload Sense and Short Circuit Protection
- Battery State Monitoring
- Multi Stage Battery Charger
- Mains Input Voltage Range Slide Selection Switch
DISPLAY
- MAINS ON
- UPS ON
- CHARGING
- OVERLOAD
- BATTERY LOW
- FAULT INDICATION
| MODEL | Super Power 1700 (24V) DG |
|---|---|
| INPUT | |
| INPUT VOLTAGE (Standard range) | 100V ~ 300V |
| INPUT VOLTAGE (Narrow Range) | 180V ~ 260V |
| OUTPUT | |
| OUTPUT VOLTAGE (Main Mode) | Same as INPUT |
| OUTPUT VOLTAGE (UPS Mode) | 200V ~ 230V + 10% |
| OUTPUT WAVE FROM (Main Mode) | Same as INPUT |
| OUTPUT WAVE FROM (UPS Mode) | TPZi Wave From (Trap Zoidal Wavefrom) |
| CHANGE-OVER | |
| SWITCHOVER (Mains>UPS / UPS>Mains) | AUTOMATIC |
| UPS TRANSFER TIME | <15msec |
| TECHNOLOGY | |
| DESIGN | Micro Controller Based Design With IPS Technology |
| BATTERY CHARGING CURRENT | Constant Charging Approx. 10% of the Rated Battery Current in AH |
| UPS OVERLOAD / UPS SHORT CIRCUIT | 110% / 300% |
| BROWNS ON MAINS VOLTAGE | 100V +40V |
| EFFICIENCY (BATTERY MODE) | >84% |
| AUTO RESET FEATURE | YES |
| INPUT DC RANGE | 21V ~ 28.4V |
| CHARGING CURRENT | 10 Amps +1 Amps |
